SURFACE SOLUTIONS INDUSTRIAL APPLICATIONS 2024
INTRODUCTION 04-10 CUTTING DISCS & 13-38 GRINDING WHEELS 2 / Contents Market Solutions 04 Your safety is our priority 06 Supporting Sustainability 07 Merchandising Solutions 08 MyAbrasives 09 Passing our knowledge onto you 10 Service & Support with you in mind 11 Introduction 14 CUTTING DISCS & GRINDING WHEELS 16-32 for Metal Fabrication & Welding 16 for Rail 29 CUTTING DISCS 33-35 for Petrol Saws 33 for Chop Saws 34 for Stationary Machines 35 Technical Information 36 COATED ABRASIVES 39-212 Introduction 40 DISCS FOR ANGLE GRINDERS 47-72 Introduction 48 Fibre discs 51 Flap discs 57 Semi-flexible discs 62 Rapid Strip 63 Rapid Blend 65 Rapid Prep 68 Polishing discs 72 DISCS FOR MINI ANGLE GRINDERS 73-92 Speedlok discs 74 Mini Flap discs 79 Non-Woven Speedlok discs 82 Rapid Strip Speedlok discs 83 Rapid Blend Speedlok discs 84 Rapid Prep Speedlok discs 86 Speedlok Buffing & Polishing discs 88 Mini Right Angle Grinder Tools & Kits 91 DISCS FOR ORBITAL MACHINE 93-108 Norton MeshPower discs 94 Self-Grip and BearTex discs 96 Screenback discs 105 Plain discs 106 BearTex floor pads 108 WHEELS 109-140 Flap wheels 110 Pneumatic Die Grinder Tools & Kits 118 Rapid Finish Convolute wheels 128 Rapid Strip wheels 134 Rapid Blend unitised wheels 136 Small unitised wheels / Mounted points 138 High strength discs 139 ROLLS 141-156 Handy rolls 142 Paper & cloth rolls 146 Norton MeshPower 151 BearTex rolls 152 Rotolo Foam rolls 154 SHEETS & SPONGES 157-170 Cut sheets 158 Norton MeshPower 159 Sheets and hand pads 163 BearTex sheets and hand pads 167 Abrasive sponges 169 BELTS 171-198 File belts 172 Portable belts 179 Narrow belts 182 Rapid Prep belts 190 SPECIALTIES 199-212 Spirabands and Cones 200 Cartridge and Spiral rolls 204 Sanding stars 208 Technical Information 210
CONTENTS SUPER ABRASIVES 283-316 WIRE BRUSHES 387-418 & CARBIDE BURRS DIAMOND TOOLS 317-374 BONDED 213-282 ABRASIVES Contents / 3 Introduction 284 DIAMOND & CBN GRINDING WHEELS 285-316 for machining round tools 288 for round tool universal grinding 291 for sharpening saw blades 293 for sharpening HSS saw blades 297 for general engineering 298 Diamond lapping compounds 306 Diamond files 307 Diamond Dressers 308 Wire brushes 389 Carbide burrs 405 Bevelling tools 415 Steel wool 418 Introduction 214 PRECISION GRINDING 221-248 Introduction & Product selection 222 Straight wheels 229 Straight & tapered cups 242 Dishes 245 Cylinders 246 Segments 247 BENCH WHEELS 249-254 Why choose Norton Starline 250 Wheel recommendation chart 251 Technical information 251 Starline bench wheels 252 Hand dressers 254 MOUNTED POINTS & WHEELS 255-264 Vitrified mounted points 258 Organic mounted points 263 DRESSING STICKS & SHARPENING STONES 265-274 Dressing sticks 266 Bench & combination oil stones 268 Abrasive & precision files 270 Abrasive slips and specialties 273 ORGANIC WHEELS & CUPS FOR SNAGGING 275-278 Snagging wheels 276 Snagging cups 276 STRAIGHT CUT-OFF WHEELS 279-282 Non-Reinforced wheels 280 Reinforced wheels 280 Introduction 318 DIAMOND BLADES 320-356 for concrete & reinforced concrete 320 for universal building materials 325 for multi materials 336 for ceramic & porcelain tiles 340 for granite, marble & natural stone 346 for asphalt & abrasive materials 350 for refractory materials 353 CUP GRINDERS 357-360 for concrete & building materials 357 DRILLING CORE BITS 361-371 for concrete 361 for universal building materials 367 Technical Information 372 STEP DRILLS 375-386 & CORE DRILL Step drills 377 Core drills 379
METAL FABRICATION At Norton, we offer abrasive solutions for rust, weld, coating and paint removal, surface blending, finishing and polishing with excellent cut rate and life. All Norton products excel in fabrication, welding, maintenance and repair operations, keeping operating cost and downtime to a minimum. TRANSPORT From grinding and shaping to edge breaking, de-burring and finishing wings and airframes, Norton can be relied upon to deliver the highest performance. On the ground, Norton reduces operational costs and increases quality and throughput in the production of engine and body components for motorcycles, cars, trucks and trains, and for rail and track maintenance. On water, the marine industry relies on our specialist abrasives for bodywork operations. TOOLING For precision grinding and sharpening of essential implements such as shank tools, milling tools knives and saw blades, high quality Norton diamond and cBN cups and wheels are the ultimate performance solutions to deal with the most demanding materials. ENERGY Norton offers complete solutions for the manufacture and maintenance of land and offshore wind turbines for OD and ID grinding, to portable cutting and finishing operations of gears and bearings, blades, vanes, seals and casings. STEEL INDUSTRY Norton abrasives for use in steel conditioning, cutting and grinding sheets, slabs, billets, bars, rounds, rolls, sheets and tubes have been designed to keep your productivity levels high and costs low. All Norton abrasives are manufactured and safety tested in accordance with the most stringent European safety standards, EN12413, ISO and oSa. MEDICAL Norton abrasives produce exceptional results, helping to manufacture quality products to the most stringent requirements of the optical, medical and metallurgical industries. Highly engineered abrasive cut-off wheels, abrasive belts, non-woven de-burring / finishing wheels and belts, bonded grinding wheels and diamond and CBN tools are used throughout the production process to produce knee and hip joints, prosthetics and medical instruments. BEARING & GEARS Norton has a full range of solutions to ensure bearings and gears are produced to the very highest standards. High performance grinding wheels with the latest innovation in bond technology; maximise efficiency and part quality. Norton profile dressers deliver a complete solution for continuous gear generation, profile grinding, bevel gear grinding, power honing. BUILDING & CONSTRUCTION Norton Clipper is a one-stop shop for all cutting, drilling, grinding and sanding jobs within the building and industrial construction markets. We can equip you with the safest and highest performing construction blades, machines and abrasives that not only help to improve your personal comfort and contribute to a greener environment, but improve our habitat. WOOD & COMPOSITES Whether you’re a carpenter, joiner, floor liner or furniture manufacturer or restorer, Norton has a complete offering for calibration, tool sharpening and sanding and finishing applications. Norton delivers innovative solutions across many industries where abrasives are an integral part of manufacture and repair processes. From cutting concrete, to grinding metal, to sanding composite materials, Norton abrasives addresses the needs of many markets, including: MARKET SOLUTIONS 4 / Introduction
Introduction / 5 INTRODUCING RAZORSTAR® FIBRE DISCS AND BELTS FEATURING ENGINEERED SHAPED CERAMIC GRAIN SHARPER THAN EVER SEE PAGE 52 FOR FIBRE DISCS AND PAGE 183 FOR BELTS HIGHER CUT RATE LONGER LIFE COOLER CUT NEW
6 / Introduction DIFFERENTIATION IN THE RANGE We have one of the widest selections of abrasive products to meet every customer requirement. The range is classified into four quality-tiers (good/better/best/Innovation) to help you choose the right product for your specific application. ++++ BEST +++++ Our best tier products are top-of-the-range solutions with an impressive, measurable impact on reduced process cost. Our better tier products are the right fit when you can’t easily measure the value of a best tier product, but still have higher expectations for performance. BETTER +++ Our good tier products promise great value with great performance you’d expect from Norton, at a competitive price. GOOD INNOVATION Norton’s innovative abrasive solutions offer outstanding productivity and versatility. ABRASIVE SAFETY STARTS WITH US. YOUR SAFETY IS OUR FIRST PRIORITY SO ALL NORTON PRODUCTS ARE MANUFACTURED IN ACCORDANCE WITH THE MOST RIGOROUS EUROPEAN AND INTERNATIONAL HEALTH, SAFETY AND ENVIRONMENTAL NORMS. FEPA As a member of the Federation of European Producers of Abrasives (FEPA), we’re always up to date with the latest technical, legal and scientific regulatory frameworks, meaning we’re always one step ahead. Together with oSa, FEPA pursues the objective of supporting both the currently attained safety standards and further future developments. oSa® As a member of the Organisation for the Safety of Abrasives (oSa), we position ourselves amongst quality manufacturers with the highest safety levels and we’re proud to carry the trademark. Through a stringent monitoring and audit system year after year, we maintain our reputation as a reliably safe and responsible producer of quality abrasives. We conform to European and International standards, EN12413, EN13236 and EN13743 for bonded, diamond and coated products and ISO 9001, 14001 and OHSAS 18001 for our manufacturing sites. This is not just because it’s a legal requirement, it’s also because we care. Opt for the oSa® trademark; tested quality products of the highest safety level. YOUR SAFETY IS OUR PRIORITY
Introduction / 7 To understand more and to see practical examples of the steps that we’ve taken and targets that we work to, for each of these five pillars, please ask your sales representative or visit: www.nortonabrasives.com SUSTAINABILITY IS AT THE CORE OF WHAT WE DO, WE HAVE CLEAR COMMITMENTS BUILT AROUND FIVE PILLARS: TAKE ACTIONS ACROSS THE SUPPLY CHAIN • Reduction of Scope 3 CO2 value chain emissions • Decarbonizing our transportation • Clear shift to greener packaging LIMIT OUR ENVIRONMENTAL IMPACT ENCOURAGE EMPLOYEE ENGAGEMENT • Reduction of energy consumption and CO2 emissions (Scope 1 & 2) • Water withdrawal and reuse • Reduction of waste to landfill, and reuse and recycle • Increased biodiversity and reduced pollution • Awareness and education programs • Ambassador networks and employee ideation SUSTAINABILITY AS A DRIVER FOR GROWTH SOLUTIONS WITH END-USERS’ SAFETY, HEALTH, COMFORT AND WELLBEING AT HEART • Decarbonisation of our customers’ applications • Environmental product declaration / Life Cycle Assessment • Circular economy, recycling services, eco-innovation • Customer centricity on safety, health, comfort & wellbeing • Surface solutions to reduce vibration, noise, dust, VOC & odour,.. • Greener solutions that respect the planet and the people Mitigating climate change means decarbonizing our economies, and here at Saint-Gobain, the goal is simple: by 2050 we must not emit any more carbon than we absorb. We must be carbon neutral, we must preserve our planets assets such as water and rare earth, and we must limit the waste that we generate. This commitment is rooted in a history of reducing our environmental impact and it is inseparable from our ambition to provide our customers with solutions to decarbonize and reduce their own environmental footprint. Our net zero ambition is also a concrete expression of our purpose, Making the world a better home! SUPPORTING SUSTAINABLITY IN THE ABRASIVES INDUSTRY
8 / Introduction NORTON DISPLAY SYSTEM • Your customers can quickly and easily find the best abrasive for their job • Encourage the sale of other products through cross selling • Reduce the workload on your sales team, let the display do the selling for you • Integrated solution with optional corner fitting fits almost any space • Free standing, space saving option also available • Optional additional graphic information system tailored to you helps your customers select the right product. To find out more about the Display System, contact your Norton representative today. POINT-OF-SALE GRAPHICS Graphic templates can be adapted to suit your requirements. Attaches using magnetic strips so you can easily change the information on display. For information about tailored designs please contact your local sales representative DISPLAY KIT TYPES PK QTY NORTON CLIPPER Kit with light (UK plug) 1 410058121 410050915 Kit without light 1 410076980 410048415 ACCESSORIES PK QTY NORTON CLIPPER Header with light 1 MTO MTO Header without light 1 Shelf 1 Drill motor hooks x2 1 Euro hooks x35 1 Core Drill hook 1 DESCRIPTION PK QTY ART NO. Portable stand 1 410090016 DISPLAY KITS • The complete kit comes with all components needed to create a full display for any product range. • Kit contains: Base x1, pegboards x4, header x1, shelf x1, display bar with 5 pins x1, legs x2, pegs x35 • Accessories can be ordered separately if required. PORTABLE DISPLAY FOR CUTTING DISCS & GRINDING WHEELS • Kit contains: Unit x1, header x1, pins x22, side panels x2 • H: 1740mm x W: 380mm x D: 580mm MERCHANDISING SOLUTIONS We have a complete set of Norton branded displays to help showcase our products in all environments, plus off the shelf point-of-sale graphics that can also be tailored to customer requirements whether that’s for cutting, grinding, stock removal, or surface preparation and finishing.
Introduction / 9 ONLINE ORDERING MADE EASY MYABRASIVES FEATURES AND SERVICES INCLUDE: • Product search: search by UPC, name, category, EAN number and filter and sort search results, • Order history and reordering: see your past orders across all platforms (EDI, ABx, phone and fax). Invoices, debit/credit notes and shipping status will also be visible in the ‘Order History’ section • Quotes: request and track quotes directly • Saved orders: save orders for future reference by putting multiple items in your cart and saving. You can also add a note to indicate future order frequency • Bulk orders: upload a CSV file directly into the system rather than having to search for each product individually • Recommended for you: shows related products you may like to order • Extra support: navigate the system with FAQs and how-to videos or contact our dedicated helpline REGISTER TODAY To register call your local customer service team and start using MyAbrasives today. MAKING ORDERING EASIER: 1. Detailed product information and specifications, including images and videos 2. Access to order confirmations, product availability and delivery lead times 3. Available from smartphones, tablets and PCs 24/7 4. Automatically creates a list of most frequently ordered products for ease of future ordering 5. Save favourite lists to make ordering quicker and easier With MyAbrasives, the ordering process is simple: Search for your product Add to basket Go to checkout
10 / Introduction YouTube Social Media Find us on YouTube: Norton Abrasives EMEA’ and click the ‘Metal Fabrication’ playlist to get answers to real life problems, select the best product for the job, and much more. Hit ‘subscribe’ to never miss a new release! Keep up to date with what’s happening at Norton via Facebook, Instagram and LinkedIn. Share your creations with us using the hashtag #Nortonabrasives, you might even get featured on one of our pages! PASSING OUR KNOWLEDGE ONTO YOU www.nortonabrasives.com With over 130 years of practical experience, Norton offers expertise, knowledge, understanding and advice and with the Norton website all of this is just a few clicks away. Whether you’re searching for a product, distributor, or looking for tips, either on a computer, phone or portable device, Norton is always by your side to offer support. Filled with articles, user guides brochures and videos, we’re always keeping you up to date with the latest news and information. At Norton, we’re always looking for new ways to bring you value. Whether that’s through our product range or additional services that increase abrasive knowledge and understanding, our aim is to help boost your abrasive sales! JOIN US! Our virtual live seminars, held by our Norton Application Engineer, Paul Gray, aim to enrich your abrasive expertise through a live demonstration of our products and processes, followed by a Q&A session where you can ‘Ask The Expert’ any questions you have related to the subject. Visit Nortonabrasives.com to find out what's on and join us for the next Live event!
Introduction / 11 TEST EXPERT The ‘Test Expert’ platform is a digital comparison tool, designed to measure efficiency improvements gained by using Norton abrasives. Our sales teams are always available to perform comparative tests with you at end-user level, quantifying savings and providing real life and real time evidence of the benefits Norton offers. We’re always at your side to provide the highest level of satisfaction. At Norton, we’re not just focused on providing great value products, but on adding value through great service. Our customers are at the heart of what we do, so we offer many support packages designed to add value to everyday processes. TRAINING Thanks to many years’ practical experience in the field, our application engineering team are able to pass on their knowledge and expertise through ‘hands-on’ training or virtual sessions designed to educate your teams and enrich their skills to help them work with your customers and find the best abrasive solutions. Whether you’re a newcomer or an experienced player in highly specialized industry, the Norton training service provides specialized and practical knowledge on how to safely use abrasive products and get the maximum performance every time. Thanks to our dedicated network of engineers, we’re able to visit you at your preferred location or alternatively, we have a number of training facilities across Europe where you’re welcome to visit. CLOSER TO YOU With manufacturing sites located in almost every European country and centrally located distribution centres with a wide shipping network, we offer a local service on a global scale, always close to you. Combine this with highly specialised sales and customer service teams, offering you support, handling enquiries and providing technical knowledge, we’re always pushing to drive business together. SERVICE & SUPPORT WITH YOU IN MIND
12 / Introduction NOTES
CUTTING DISCS & GRINDING WHEELS Introduction 14 CUTTING DISCS & GRINDING WHEELS 14-32 for Metal Fabrication & Welding 14 for Rail 29 CUTTING DISCS 33-35 for Petrol Saws 33 for Chop Saws 34 for Stationary Machines 35 Technical Information 36 CUTTING DISCS & GRINDING WHEELS
14 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA PRODUCT SELECTION GUIDE CUTTING DISCS FOR ANGLE AND STRAIGHT GRINDERS Highly recommended 3 UNDERSTANDING THE PRODUCT 1 Best quality tier 2 Application material 3 Diameter x Thickness x Hole 4 Product specification 5 Maximum peripheral speed 6 Machine cutting or grinding 7 Product code 8 OSA certification 9 EN12413 The Norton range of Cutting Discs and Grinding Wheels for portable and fixed machines provide superior performance in the most stringent working environment. The product range includes state-of-the-art solutions for Cutting-off, Grinding, and Surface Finishing operations on any materials related to industrial fabrication markets. Norton, the industry’s most comprehensive Cutting-off and Grinding product line. INTRODUCTION 1 2 3 4 5 6 7 8 9 INNOVATION +++++ +++++ MATERIALS NORTON QUANTUM3 X-TREME PRO X-TREME VULCAN RAIL STARLINE 1-2-3 ALU MULTI MATERIAL Steel / construction steel 3 3 3 3 3 3 3 3 Low alloy 3 3 3 3 3 3 3 3 High alloy 3 3 3 3 Thin sheets, plates, profiles 3 3 3 3 3 3 3 Stainless steel / inox 3 3 3 3 3 3 Cast iron Non-ferrous 3 3 Titanium 3 3 3 Stone concrete 3 Tiles / ceramics 3 Rail hard grade 3 Rail medium grade 3 Rail soft grade 3 Glass ceramics PVC 3 ++++ +++ ++++ CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 15 www.nortonabrasives.com PRODUCT SELECTION GUIDE GRINDING WHEELS FOR ANGLE GRINDERS Highly recommended 3 MATERIALS NORTON QUANTUM3 X-TREME VULCAN STARLINE 1-2-3 ALU MULTI MATERIAL Steel / construction steel 3 3 3 3 3 3 Low alloy 3 3 3 3 3 3 High alloy 3 3 Thin sheets, plates, profiles 3 3 3 3 3 Stainless steel / inox 3 3 3 3 3 Cast iron Non-ferrous 3 3 Titanium 3 3 3 3 Stone concrete 3 3 Tiles / ceramics 3 3 Glass ceramics PVC 3 3 INNOVATION +++++ +++ ++++ OPERATOR COMFORT... Reduced hand fatigue from less cutting vibration. LESS GRINDING TIME… A sharper wheel for the highest metal removal and faster cutting action. LESS DOWNTIME &WASTE... From longer wheel life, using fewer wheels. 1 2 3 Norton Quantum3 CUTTING DISCS & GRINDING WHEELS
16 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Cutting performance taken to a new level in comfort, life and speed • For precision, speed and the most accurate cut with reduced vibration levels, helping you to cut more comfortably for longer • 1.3mm thickness is ideal for pipe cutting • Ceramic grains give this wheel it’s unique character. 1.0mm for ultimate speed and comfort. 1.6mm for absolute stability and longest life • Delivers best in class performance on Steel and Stainless Steel NORTON QUANTUM3 INNOVATION ULTRA THIN CUTTING DISCS CERAMIC ADVANTAGE CERAMIC CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING The use of abrasives in secondary steel industries is vast; from ship building and production of domestic appliances, automotive and construction components, special profiles, pipes and electrical goods to maintenance and repair of equipment, tools and machines. AIRTIGHT PACKAGING Stops atmosphere and weather elements eroding product performance DESICCANT POUCH Holds thousands of tiny pores that absorb and trap moisture in X-TEND PERFORMANCE is proven to be up to 40% better than standard packaging METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23* NQ 60 ZZ 25 66253371347 1.3x22.23* NQ 60 ZZ 25 66253371348 1.6x22.23* NQ 46 ZZ 25 66253371349 125 1.0x22.23* NQ 60 ZZ 25 66253371350 1.3x22.23* NQ 60 ZZ 25 66253371351 1.6x22.23* NQ 46 ZZ 25 66253371352 180 1.6x22.23 NQ 46 ZZ 25 66253371354 230 1.9x22.23 NQ 46 ZZ 25 66253371355 TYPE 42 115 0.8x22.23 NQ 60 ZZ 25 66252846642 125 0.8x22.23 NQ 60 ZZ 25 66252846643 CORDLESS COMPATIBLE * X-TEND included TUBS MADE FROM 100% RECYCLED PLASTIC. CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 17 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 125 2.0x22.23 NQ 36 Y 25 66252848856 125 2.5x22.23 NQ 24 P 25 66252845954 230 2.5x22.23 NQ 24 P 25 66252846173 TYPE 42 125 2.5x22.23 NQ 24 P 25 66252832258 180 2.5x22.23 NQ 24 P 25 66252845041 230 2.5x22.23 NQ 24 P 25 66252846174 • Greater wheel thickness for a more robust cut • Ceramic grain provides a fast, sharp cut time and time again • Incomparable speed in rough cutting applications on black steel • Ideal for large steel projects, shipyards, steel construction and general engineering NORTON QUANTUM3 INNOVATION CUTTING DISCS METAL INOX CERAMIC ADVANTAGE CERAMIC ADVANTAGE EXPERIENCE EXTRA SMOOTH CUTTING ACTION, THANKS TO OUR PREMIUM CERAMIC GRAIN. HOWWILL IT BENEFIT YOU? Norton Conventional Ceramic Wheel Norton Zirconia Wheel Norton Quantum3 Ceramic Wheel CUTTING DISCS & GRINDING WHEELS
18 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING • Ideal for light grinding on thin walled workpieces • Combines speed and precision in grinding, deburring and bevelling • At 3mm thickness, less energy is needed to power up and use the wheel • Self-sharpening ceramic grain technology for fast material removal resulting in less grinding time TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 3.0x22.23 NQ 30 S 10 66252846608 125 3.0x22.23 NQ 30 S 10 66252846609 NORTON QUANTUM3 INNOVATION LIGHT COMFORT GRINDING METAL INOX CUT THE CORD NOT THE POWER At 3mm thickness, less energy is needed to power up and use the wheel. Get up to 50% longer battery life from cordless grinders. CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 19 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 7.0x22.23 NQ 24 P 10 66253371361 125 7.0x22.23 NQ 24 P 10 66253371362 125 7.0x22.23 NQ 24 N 10 66252839321 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 180 7.0x22.23 NQ 24 P 10 66253371364 230 7.0x22.23 NQ 24 P 10 66253371365 230 7.0x22.23 NQ 24 N 10 66252839322 • Self-sharpening ceramic grain technology for high material removal and less grinding time • More comfortable to use with reduced hand fatigue from less cutting vibration • Longer wheel life means less downtime and waste, fewer wheels needed • Offers true savings in grinding processes • Optimised wheel for use on high frequency machines under high pressure, extra safe in all working conditions • Self -sharpening ceramic grain technology for high material removal and less grinding time • More comfortable to use with reduced hand fatigue from less cutting vibration • Longer wheel life means less downtime and waste, fewer wheels needed NORTON QUANTUM3 INNOVATION GRINDING WHEELS NORTON QUANTUM3 INNOVATION HIGH FREQUENCY GRINDING WHEELS METAL INOX METAL INOX INOX INOX High Frequency machines will not reduce in revolutions when grinding pressure is increased. When using high pressure on standard or non-reinforced wheels and machines, the risk of wheel breakage is high. Also, under low pressure, non-reinforced wheels can show cracks due to fatigue within the abrasive running at high revolutions. High Frequency reinforced grinding wheels ensure safe working conditions in all circumstances. Norton Quantum3 CUTTING DISCS & GRINDING WHEELS
20 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. COMBINATION WHEELS 115 4.2x22.23 NQ 24 R 20 66253371356 TYPE 27 125 4.2x22.23 NQ 24 R 20 66253371357 180 4.2x22.23 NQ 24 R 20 66253371359 230 4.2x22.23 NQ 24 R 20 66253371360 • Fast grinding formula, gets the job done quickly • Improved grinding control ensures precision and accuracy • Easy access in hard to grind areas, corners and inside tight grooves • Smoother feel, reduced fatigue and improved operator comfort • Boost the amperage on cordless grinders due to light weight / fast cutting • Ideal for pipe cutting NORTON QUANTUM3 INNOVATION COMBINATION WHEEL CERAMIC ADVANTAGE METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 ZA60X 25 66252846978 125 1.0x22.23 ZA60X 25 66252846979 1.6x22.23 ZA46X 25 66252846980 2.0x22.23 ZA36X 25 66252846981 180 1.6x22.23 ZA46X 25 66252846983 230 1.9x22.23 ZA46X 25 66252846984 X-TREME PRO HEAVY DUTY +++++ • Longest life reduces overall process cost, with more cuts per disc • Fast, straight, clean and burr free cutting reduces the need for rework • Choose Norton X-treme Pro for jobs that require that extra cutting performance METAL INOX CORDLESS COMPATIBLE TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 125 4.2x22.23 A30V 20 66252846985 7.0x22.23 A30V 10 66252846986 180 4.2x22.23 A30V 20 66252846988 230 7.0x22.23 A30V 10 66252846990 METAL INOX CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 21 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 A 60 V 25 66252919427 1.6x22.23 A 46 V 25 66252920339 2.0x22.23 A 36 V 25 66252920340 125 1.0x22.23 A 60 V 25 66252920341 1.3x22.23 A 60 V 25 66252837992 1.6x22.23 A 46 V 25 66252920342 2.0x22.23 A 36 V 25 66252920343 2.5x22.23 A 36 V 25 66252920350 180 1.6x22.23 A 46 V 25 66252920345 2.0x22.23 A 36 V 25 66252920346 230 1.9x22.23 A 36 V 25 66252920348 2.0x22.23 A 36 W 25 66252920360 2.5x22.23 A 36 V 25 66252920349 TYPE 42 115 2.5x22.23 A 36 V 25 66252921567 125 2.5x22.23 A 36 V 25 66252918816 230 2.5x22.23 A 36 V 25 66252918818 X-TREME +++++ • High performance aluminium oxide grain for fast and high material removal • Superior bond system holds the grain for long wheel life, resulting in less wheel erosion • Ideal for heavy industrial use on all hard steel types and alloys METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 7.0x22.23 A 24 R 10 66252918822 125 4.0x22.23 A 24 R 10 66252950672 7.0x22.23 A 24 R 10 66252918823 180 7.0x22.23 A 24 R 10 66252918824 230 7.0x22.23 A 24 R 10 66252918825 METAL INOX CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
22 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA * Made-to-order NEW CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 A 60 S 25 66252925431 1.6x22.23 A 46 S 25 66252925432 2.0x22.23 A 30 S 25 66252925437 2.5x22.23 A 30 S 25 66252925442 3.0x22.23 A 30 S 25 66252925447 125 1.0x22.23 A 60 S 25 66252925433 1.6x22.23 A 46 S 25 66252925434 2.0x22.23 A 30 S 25 66252925438 2.5x22.23 A 30 S 25 66252925443 3.0x22.23 A 30 S 25 66252925448 180 1.6x22.23 A 46 S 25 66252925435 2.0x22.23 A 30 S 25 66252925440 2.5x22.23 A 30 S 25 66252925445 3.0x22.23 A 30 S 25 66252925449 230 1.9x22.23 A 46 S 25 66252925436 2.0x22.23 A 30 S 25 66252925441 2.5x22.23 A 30 S 25 66252925446 3.0x22.23 A 30 S 25 66252925450 TYPE 42 100 3.2x22.23 A 30 S 25 66252835417* 115 2.5x22.23 A 30 S 25 66252925490 3.2x22.23 A 30 S 25 66252925494 125 2.5x22.23 A 30 S 25 66252925491 3.2x22.23 A 30 S 25 66252925495 180 2.5x22.23 A 30 S 25 66252925492 3.2x22.23 A 30 S 25 66252925497 230 1.9x22.23 A 46 S 25 66252849388 2.5x22.23 A 30 S 25 66252925493 3.2x22.23 A 30 S 25 66252925498 • Great price versus performance ratio • The general purpose range of cutting discs VULCAN ++++ CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 23 www.nortonabrasives.com VULCAN FAST CUT ++++ METAL INOX • For use on low and medium power machines • Hard steel types TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 180 6.4x22.23 A 30 P 10 66252830805 230 6.4x22.23 A 30 P 10 66252830807 CUTTING DISCS & GRINDING WHEELS
24 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6.4x22.23 A 30 S 10 66252925522 125 4.0x22.23 A 30 S 20 66252925519 6.4x22.23 A 30 S 10 66252925523 8.0x22.23 A 30 S 10 66252925524 180 6.4x22.23 A 30 S 10 66252925526 8.0x22.23 A 30 S 10 66252925527 230 4.0x22.23 A 30 S 20 66252925521 6.4x22.23 A 30 S 10 66252925529 METAL INOX • Great price versus performance ratio • The general purpose range of grinding wheels VULCAN ++++ CORDLESS COMPATIBLE STONE STONE CAST IRON TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 42 115 3.2x22.23 C 30 R 25 66252925500 125 3.2x22.23 C 30 R 25 66252925501 230 3.2x22.23 C 30 R 25 66252925503 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6.4x22.23 C 30 R 10 66252925533 125 6.4x22.23 C 30 R 10 66252925534 180 6.4x22.23 C 30 R 10 66252925535 230 6.4x22.23 C 30 R 10 66252925537 NEW VULCAN COMFORT ADVANTAGE ++++ METAL INOX • Improved comfort in use • Reduced vibration • Smoother wheel wear for reduced chipping • Higher metal removal rates • Suitable for low power machines • Lower pressure needed, reduces operator fatigue • Reduces workpiece burn TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6.4x22.23 A 30 P 10 66252830803 125 6.4x22.23 A 30 P 10 66252830804 CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 25 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS - ANGLE GRINDER CUTTING DISCS - LARGE DIAMETER TYPE 41 115 1.0x22.23 A 60 R 25 66252837243 1.6x22.23 A 46 R 25 66252837244 2.5x22.23 A 30 P 25 66252837249 125 1.0x22.23 A 60 R 25 66252837245 1.6x22.23 A 46 R 25 66252837246 2.5x22.23 A 30 P 25 66252837250 180 1.6x22.23 A 46 R 25 66252837247 2.5x22.23 A 30 P 25 66252837251 230 1.9x22.23 A 46 S 25 66252843278 2.0x22.23 A 36 R 25 66252837248 2.5x22.23 A 30 P 25 66252837253 TYPE 42 115 3.2x22.23 A 30 P 25 66252837275 125 3.2x22.23 A 30 P 25 66252837276 180 3.0 x 22.23 A 30 S 25 66252837277 230 3.2x22.23 A 30 P 25 66252837278 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6.4x22.23 A 24 Q 10 66252837263 125 6.4x22.23 A 24 Q 10 66252837264 180 6.4x22.23 A 24 Q 10 66252837268 230 6.4x22.23 A 24 Q 10 66252837269 STARLINE +++ • Good material removal and cut rate • For general trade and general usage METAL INOX CORDLESS COMPATIBLE METAL INOX CUTTING DISCS & GRINDING WHEELS
26 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Ceramic grain removes material quickly on a variety of different materials, one disc replaces many • At 3mm thick, the lightweight wheel ensures precision and accuracy during grinding • Easy access to hard to grind areas, corners and tight grooves • Smoother feel, reduced fatigue and improved operator comfort MULTI MATERIAL LIGHT COMFORT GRINDING ADAPTS TO ITS SURROUNDINGS TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 3.0x22.23 C 30 S 10 66252846610 125 3.0x22.23 C 30 S 10 66252846611 • One wheel for all materials • The easy choice in general trade • No lost time due to wheel changing • Quick, comfortable and versatile MULTI MATERIAL CUTTING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 C 60 T 25 66252833258 1.6x22.23 C 46 T 25 66252828951 125 1.0x22.23 C 60 T 25 66252918924 1.6x22.23 C 46 T 25 66252828952 180 1.6x22.23 C 46 T 25 66252926730 230 1.9x22.23 C 46 T 25 66252918925 ALU METAL INOX STONE C.TILES PVC ALU METAL INOX STONE C.TILES PVC CUT THE CORD NOT THE POWER At 3mm thickness, less energy is needed to power up and use the wheel. Get up to 50% longer battery life from cordless grinders. CORDLESS COMPATIBLE CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 27 www.nortonabrasives.com • Specially developed grain and bond system, designed to cut through aluminium and non-ferrous metals without clogging • Counteracts loading and wheel glazing for fast, easy and free cutting action on all non-ferrous material NORTON ALU TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 A 60 Q 25 66252828236** 1.6x22.23 A 46 Q 25 66252828233 125 1.0x22.23 A 60 Q 25 66252828237** 1.6x22.23 A 46 N 25 66252839270 1.6x22.23 A 46 Q 25 66252828234 2.5x22.23 A 36 Q 25 66252828227 180 2.5x22.23 A 36 Q 25 66252828229 230 1.9x22.23 A 46 N 25 66252839271 1.9x22.23 A 46 Q 25 66252828235 TYPE 42 230 3.0x22.23 A 36 Q 25 66252828231 ALU ALU CORDLESS COMPATIBLE TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 7.0x22.23 A 36 Q 10 66252849497* ** 125 7.0x22.23 A 36 Q 10 66252828228** 180 7.0x22.23 A 36 Q 10 66252828230 230 7.0x22.23 A 36 Q 10 66252828232 NEW NEW * Made-to-order ** Up to +30% performance improvement NEW NEW A specialist range of discs designed for cutting and grinding Aluminium. New, upgraded wheels now provide 30% better performance with higher material removal rates, longer life and improved operator comfort. CUTTING DISCS & GRINDING WHEELS
28 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Cut, grind and finish with one wheel • Fine grit for a good, uniform finish when used at 15 degrees • No lost time due to wheel changing • Three layers of reinforcement for maximum safety in use 1-2-3 THE ALL IN ONE SOLUTION TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. COMBINATION WHEELS TYPE 27 115 2.2x22.23 A 46 S 25 66252829704 125 2.2x22.23 A 46 S 25 66252921592 METAL INOX CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 29 www.nortonabrasives.com CUTTING DISCS FOR RAIL The Norton Rail range provides high performance wheels for demanding operations. Rail cutting requires precision, speed and power and Norton Rail is a complete program of cutting wheels suitable for any rail type (subway, tram, train) and any rail cutting machine with a clamping device (electrical and petrol). AS RAIL TRACK TECHNOLOGY CONTINUES TO MAKE MAJOR ADVANCES, NORTON IS GENERATING POWERFUL, INNOVATIVE, USER-FRIENDLY SOLUTIONS TO CUT, SHAPE AND GRIND HEAVY DUTY STEELS CUTTING DISCS & GRINDING WHEELS
30 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING-OFF Arrange the workpiece so that a uniform section can be cut UNDERSTANDING THE PRODUCT TECHNICAL INFORMATION 1 Product code 2 Application material 3 Diameter x Thickness x Hole 4 Product specification 5 Maximum peripheral speed 6 Machine cutting 7 Safety pictograms 8 OSA certification 9 EN standard BF 41 FLAT CUTTING-OFF WHEELS Rail cutting-off wheels are available in 300mm for clamped rail cutting machines that operate at 80m/s. For clamped rail cutting machines that operate on 100m/s wheels are available in 350mm and 400mm. Bore dimensions of the cutting wheel can be adjusted using reduction rings that come with the original machine. 1 2 3 4 5 6 7 8 9 1. 2. 3. KEY: Oscillate the wheel, swing the machine for quickest and cleanest cut Direction of cut CUTTING DISCS FOR RAIL CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 31 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 356 4.0x22.23 NQ 24 Q 10 66252845405 4.0x25.4 NQ 24 Q 10 66252845406 406 4.0x25.4 NQ 24 Q 10 66252846183 • Designed for comfort, built to last and 'made to bite' • Long product life reduces the number of replacement discs, reducing total abrasive cost • High speed cutting makes the overall rail repair process more efficient • The wheel does the work and less vibrations are felt through the machine reducing the risk of white finger NORTON QUANTUM3 RAIL INNOVATION NORTON QUANTUM3 RAIL DESIGNED FOR COMFORT, BUILT TO LAST, AND ‘MADE TO BITE.’ INNOVATION BOND TECHNOLOGY COMBINATION OF SHARP PREMIUM ABRASIVE GRAINS FAST CUTTING LONGER LIFE + = "The Norton Quantum3 really speeds up the cutting process - I can get through 3 cuts per wheel now, maybe even more, instead of struggling to get through one with the wheels I was using before. And it's not just that, it's much easier to use, kind of glides through the rail piece with ease. I'll definitely be switching over to Norton Quantum3" Don't just take our word for it, see what our customers have to say.... CERAMIC ADVANTAGE CERAMIC ADVANTAGE RAIL METAL CUTTING DISCS & GRINDING WHEELS
32 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA RAIL ++++ RAIL METAL TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 356 4.0x25.4 ZA 24 Q Zirconia Medium 10 66252830924 406 4.0x25.4 ZA 24 Q Zirconia Medium 10 66252833665 RAIL ++++ • For a precise, straight and fast cut on rail, tram and subway track • Low vibration, consistent performance throughout wheel life • Hard, medium and soft wheels available • High quality cut to help generate a perfect weld RAIL METAL TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 350 4.0x25.4 A 24 T Hard 10 66252829588 4.0x25.4 A 24 P Soft 10 66252828620 4.0x25.4 A 24 Q Medium 10 66252833554 400 4.0x25.4 A 24 P Soft 10 66252919130 CUTTING DISCS FOR RAIL CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 33 www.nortonabrasives.com CUTTING DISCS FOR PETROL SAWS Norton’s cutting wheels for petrol saws provide high value and high performance in construction and demolition. TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 300 3.5x20.0 A 30 S 10 66252925457 3.5x22.23 A 30 S 10 66252925458 VULCAN ++++ • General purpose cutting discs for all steel petrol saw applications • Straight, fast cutting throughout long wheel life METAL CUTTING DISCS & GRINDING WHEELS
34 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 300 2.8x25.4 A 30 S 10 66252925460 356 3.0x25.4 A 30 S 10 66252925462 400 3.2x25.4 A 30 S 10 66252925464 3.2x32.0 A 30 S 10 66252925465* VULCAN ++++ • Clean and straight cutting on portable chop saws and fixed machines • Mechanical reinforcement for cutting metal and inox safely METAL INOX CUTTING DISCS FOR CHOP SAWS Norton’s cutting wheels for chop saws provide high value and high performance in construction, fabrication, foundry and maintenance industries. * Made-to-order CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 35 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 400 4.5x32.0 C 30 R 10 66252925484 300 3.0x32.0 A 30 S 10 66252925466 3.0x32.0* A 30 S 10 66252925475 3.5x32.0 A 30 S 10 66252925468 356 3.5x25.4 A 30 S 10 66252925469 3.5x32.0 A 30 S 10 66252925470 3.5x32.0* A 30 S 10 66252925476 400 3.5x25.4 A 30 S 10 66252925477 4.0x25.4 A 30 S 10 66252925472 4.0x32.0 A 30 S 10 66252925473 4.0x32.0* A 30 S 10 66252925478 4.5x32.0 A 30 S 10 66252925474 VULCAN ++++ • Long wheel life with quick and free cutting • Cuts without burning, blueing or splintering the metal • Use under constant power in heavy cut-off applications • Double, full external mechanical reinforcement for excellent safety and stability METAL CUTTING DISCS FOR STATIONARY MACHINES Norton’s cutting wheels for stationary machines provide high value and high performance in construction, fabrication and foundry industries. STONE CAST IRON * Max Operating Speed 100m/s CUTTING DISCS & GRINDING WHEELS
36 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA TECHNICAL INFORMATION SHAPE SPECIFICATION SYSTEM BF 27 BF 41 BF 42 DEPRESSED CENTRE GRINDING WHEELS FLAT CUTTING DISCS DEPRESSED CENTRE CUTTING DISCS Available in diameters 76-230mm for hand-held machines. Available in diameters 50-400mm for hand-held machines and 250-400mm for stationary machines. Available in diameters 76-230mm for hand-held machines. Application: grinding Application: cutting-off Application: cutting-off PERSONAL PROTECTION Safety goggles, ear defenders, safety gloves, dust masks and, if conditions are severe, additional face protection. Leather aprons and safety shoes must be worn. Do not use if damaged Do not use for face grinding (ISO 7010) Do not use for wet grinding (ISO 7010) Do not use with hand-held grinding machine (ISO 7010) Refer to instruction manual/ booklet (ISO 7010) Wear ear protection (ISO 7010) Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Wear a mask (ISO 7010) Only permitted for grinding at an angle greater than 10° Only suitable for totally enclosed machines Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do n Do not use for wet grinding (ISO7010) Only suitable Wear e Wear pr Refer to instru Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithh Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindi gmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suit ble for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010 Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged rinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (IS 7010) Refer to instruction manual/book e (ISO 7010) ISO 7010) wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) on (ISO 7010) an angle greater than 10° h a back-up pad rinding (ISO7010) Do not use if damaged Do ot use for w t g indin (ISO7010) Only suitable for totally-enc os d machines Wear eye p otection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a m sk (ISO 7010) Only suitable for w t g indin Donot usewithhand- eldgrindingmachine (ISO7010) Wear ear p otection (ISO 7010) Only permitted for grinding at an angle greater tha 10° Only t be used with a back-up pad Do not use for face grindin (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet gri ding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/bookl t (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (IS 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective lov s (ISO 7010) Refer to instruc ion ma ual/booklet (ISO 7010) Wear mask (ISO 7010) On y uitable f r wet grindin Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for gr ding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only su table for totally-enclosed machines Wear eye protection (ISO 7010) Wea protect ve gloves (ISO 7010) Ref r t instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for we grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protectio (ISO 7010) Only p mitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 701 ) Wear protective loves (ISO 7010) Refer to ins ruction manual/b oklet (ISO 7010) W ar a mask (ISO 7010) O ly suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) TECHNICAL INFORMATION CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 37 www.nortonabrasives.com METAL RING WITH VALIDITY DATE V = VALIDITY DATE (PRODUCTION QUARTER + 3 YEAR) V01 V04 V07 V10 1st quarter 2nd quarter 3rd quarter 4th quarter EXAMPLE: V04/2024 indicates production in the 2nd quarter of 2021 and usage before the 2nd quarter of 2024 Sparks should be directed away from the face and body, if possible towards the floor. Dust extraction equipment must be used whenever it is available. The instructions for use given by the abrasive manufacturer must be followed e.g. ‘Not to be used without a support’, or ‘Not to be used for wet grinding’. The workpiece must be firmly fixed before grinding starts. Check all abrasives visually before use and make certain that the product is suitable for the application. No modifications should be made to abrasive products after delivery. When using a portable grinder always switch it off and allow the spindle to stop completely before putting the tool down. OPERATING SPEEDS Norton products are designed and tested for certain applications and operating speeds. Choose a wheel suitable for the application material. Suitable materials are indicated on the wheel label. Before mounting the grinding or cutting disc on the machine, ensure that the operating speed of the machine does not exceed the maximum operating speed as it is marked on the product. GENERAL PRECAUTIONS Safety instructions provided by the machine manufacturers must be followed. All guards, covers and hoods must be in place on the machine during grinding, and should not be modified in any way. Abrasives should not be used near inflammable material. WHEEL DIAMETER (mm) SPEED CONVERSION FOLLOWING EN 12413 MAXIMUM OPERATING SPEED (RPM) for resinoid bonded cutting discs & grinding wheels in handheld and stationary operations 80 100 50/51 30600 38200 63/65 24300 30250 76 20150 25150 100/102 15300 19100 115 13300 16650 125 12250 15300 150/152 10200 12700 180 8500 10650 230 6650 8350 300/305 5100 6400 350/356 4400 5500 400/406 3850 4800 CUTTING DISCS & GRINDING WHEELS
38 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA TECHNICAL INFORMATION SAFETY ADVICE DOs Always handle and store wheels carefully. Cutting discs should be stacked horizontally and flat, preferably on a steel base plate. Depressed centre wheels should be placed on top of each other or stored in the original packaging Always visually inspect all wheels before mounting for possible damage in transit Always use a safety guard and ensure that it is correctly positioned and securely fitted. It should cover at least one half of the wheel and protect the operator in the unlikely event of a wheel breakage. NON-REINFORCED CUTTING DISCS SHOULD ONLY BE USED ON FIXED MACHINES AND SHOULD BE CORRECTLY GUARDED. Always switch ‘OFF’ the power at supply source and/or remove the plug from the socket before changing the wheel Always ensure that the spindle speed of the machine does not exceed the operating speed marked on the wheel Always use the correct wheel mounting flanges and ensure that they are undamaged, clean and free from burrs SEE EN 12413 Allow newly mounted wheels to run at operating speed, with the guard in place, for a reasonable time before cutting or grinding Always wear EYE PROTECTION Always wear appropriate safety clothing such as DUST MASK, GLOVES, EAR PROTECTION, OVERALLS AND SAFETY SHOES Always have machine speeds checked regularly, especially after maintenance or repair. Machines fitted with speed control devices (Governors), must be properly maintained at all times Check tension of driving belts, where fitted, on a regular basis. Belts must be kept tight to ensure full power transmission. Always secure the workpiece firmly while it is being cut or ground Put portable machines in suitable cradles, when not being used, to avoid damage to the wheel Always use a portable machine in a comfortable position, where the workpiece is well balanced and the machine is well supported Grind at an angle above 30 degrees to the workpiece with a depressed centre grinding wheel Keep the working area around cutting and grinding operations clear. It is very dangerous if an operator trips and falls with an operating machine in his hands DON’Ts Handle wheels roughly Use non-reinforced cutting discs on portable machines Store wheels in a damp atmosphere or in extreme temperatures Mount a damaged wheel Tighten the mounting nut or locking flange excessively. To do so can distort the flanges Force a wheel onto a machine spindle Use mounting flanges which are incorrect, damaged, dirty or burred Use blotters with depressed centre wheels less than or equal to 406mm (EN 12413) Use a machine which is not in good mechanical condition Use a machine without a wheel guard Use wheels without proper ventilation or dust protection equipment Apply side pressure to cutting discs. You should not bend the wheel Stop the wheel by applying pressure to the periphery or face. Always switch the machine off and allow the wheel to stop revolving Allow the wheel to be trapped or pinched in the cut Apply excessive pressure onto the wheel so that the driving motor slows down Grind on the side of cutting discs or depressed centre wheels below 4,0mm thickness Drop or lower a portable machine by the cable or airline onto the floor. A wheel can be easily cracked, if it is put down hard, by the weight of the machine. This is a common cause of wheel breakage Grind with a depressed centre grinding wheel at an angle below 30 degrees to the workpiece Use a machine in a position where you do not have full control of the machine and you are not well balanced CUTTING DISCS & GRINDING WHEELS
